GRAPPLE RX51 CV

Material number: 94290759
Product line: Accessories

Product images shown are for illustration purpose only. The actual product may vary.

Description

The RX31 grapple is used in forestry machine loaders, and the RX50 is suitable for larger loaders.

Attributes

Closing Force: 17
Max Load (kg): 5,000
Tine Spread (mm): 1960
Volume Max (liters): 0.35
Weight (kg): 265
Width (mm): 590

Model specifications

Log handling grapples	RX 31	RX 31CV (with lock valve)	RX 51	RX 51CV (with lock valve)
Item Part No	94290891	94290785	94290890	94290759
Closing Force	14.1	14.1	17	17
Max Load (kg)	4,000	4,000	5,000	5,000
Tine Spread (mm)	1640	1640	1960	1960
Volume Max (liters)	0.35	0.35	0.35	0.35
Weight (kg)	200	200	265	265
Width (mm)	486	486	590	590
Detail	Variant detail	Variant detail	Variant detail	Current variant
