OIL TANK,ALUMINIUM 100L

Material number: 3395081
Product line: Accessories

Product images shown are for illustration purpose only. The actual product may vary.

Description

Tanks are the origin of the hydraulic oil your machine is using to run. Hiab original tanks are designed to perform with the crane.

Attributes

Height (mm): 674
Length (mm): 708
Return Filter Capacity: 280
Suction Outlet Rear: 1
Suction Outlet Underneath: 1
Volume Max (liters): 100
Weight (kg): 29
Width (mm): 462

Model specifications

Oil tanks	LARGE FILTER (ALUMINIUM)	SMALL FILTER (ALUMINIUM)
Item Part No	3395081	3395073
Height (mm)	674	674
Length (mm)	708	708
Return Filter Capacity	280	180
Suction Outlet Rear	1	1
Suction Outlet Underneath	1	1
Volume Max (liters)	100	100
Weight (kg)	29	29
Width (mm)	462	462
Detail	Current variant	Variant detail
