GRAPPLE TX56 CV

Material number: 94290977
Product line: Accessories

Product images shown are for illustration purpose only. The actual product may vary.

Description

Hiab accessories are designed to help you to perform your daily job faster and easier.

Attributes

Closing Force: 21.7
Max Load (kg): 9,000
Tine Spread (mm): 2010
Volume Max (liters): 0.5
Weight (kg): 340
Width (mm): 558

Model specifications

Log handling grapples	TX 56	TX 56B	TX 56B CV (with lock valve)	TX 56CV (with lock valve)	TX 86B	TX 86B CV (with lock valve)	TX 811B	TX 811B CV (with lock valve)
Item Part No	94290940	94290980	94290978	94290977	94290970	94290979	94290981	94290949
Closing Force	21.7	21.7	21.7	21.7	19.1	19.1	19.1	19.1
Max Load (kg)	9,000	9,000	9,000	9,000	9,000	9,000	9,000	9,000
Tine Spread (mm)	2010	1975	1975	2010	2260	2260	2260	2260
Volume Max (liters)	0.5	0.5	0.5	0.5	0.8	0.8	0.8	0.8
Weight (kg)	340	345	345	340	360	360	455	455
Width (mm)	558	558	558	558	558	558	1,000	1,000
Detail	Variant detail	Variant detail	Variant detail	Current variant	Variant detail	Variant detail	Variant detail	Variant detail
